Product DescriptionCompany Info.<>
- Model:
- JXFY2020-01
- Working mode:
- Ultrasonic grinding machine
- Applicable material:
- /
- Application field:
- Suitable for use in various plant tissues including roots, stems,
- Processing lot:
- /
- Driving power:
- / kw
- Grinding basket capacity:
- /
- Medium size:
- /
- Travel:
- /
- Overall dimension:
- 400*280*530 m
- Weight:
- 30 kg
- Driving mode:
- /
The crushing of bones and teeth is an important biological evidence test in forensic science. Hard physical evidence such as bones and teeth extracted from the scene of the case usually needs to be crushed and ground. After crushing physical evidence such as bones and teeth, genotyping analysis can be carried out directly to obtain relevant genetic information of victims or victims.
Product overview:
Shanghai Jingxin Bone and Teeth Crusher is mainly used in DNA laboratory to detect bones and teeth pretreatment or its transformation needs to crush teeth bones. Crushing process using disposable or can be repeatedly sterilized crushing tank, can prevent environmental pollution and cross-contamination, has high practical value.
Clean the bone surface layer and dirt with scalpel and saw into small pieces, clean the tooth surface, soak in 5%(W/V ) sodium hypochlorite solution for 15 min, discard sodium hypochlorite solution, wash with distilled water for 3 times to remove sodium hypochlorite, soak in absolute ethanol for 15 min to remove residual water {5}, dry in fume hood, grind bone slices and teeth into bone powder and tooth powder with Shanghai Jingxin bone and tooth grinder for later use.
Product use:
1. Used in DNA laboratory of public security judicial system, bone and tooth crushing;
2. It is suitable for grinding and crushing all kinds of plant tissues including roots, stems, leaves, flowers, fruits and seeds.
3. It is suitable for grinding and crushing all kinds of animal tissues including brain, lymph node and muscle.
4. Suitable for grinding and crushing fungi, bacteria including yeast, Escherichia coli and other samples;
5. Suitable for grinding and crushing food and medicine;
6. Suitable for grinding and crushing volatile samples including coal, oil shale, wax products and other samples;
7. It is suitable for grinding and crushing plastic, polymer including PE, PS, textile, resin and other samples.
Bone and tooth crusher performance indicators:major parameter
parameter scale
application area
Tissue homogenization, grinding, cell disruption, homogenization, material dispersion, preparation, sample mixing, shaking
Compatible sample sizes
48*(0.2-0.5mL)、48*2mL 12*5mL、8*(7-15)mL、2*25mL、2*50mL
size of incoming and outgoing material
No requirement for feed, according to adapter size; discharge particle size ~5um
homogenization velocity
0 70 Hz/s, i.e. oscillation times 300-4000 times/min
Grinding ball diameter/material
0.1-30mm /stainless steel, chrome steel, zirconium oxide, tungsten carbide, quartz sand
lapping way
Wet grinding, dry grinding, low temperature grinding can be
Outline size
400*280*530
weight
30KG
liquid crystal display
LCD screen display for easy and intuitive operation
working hours
0-9999s, user can set it
acceleration/deceleration
Greater speed in 2 seconds/lesser speed in 2 seconds
noise level
<55dB
Upgradable freezing function
are
